Bridgecenter-10G
Bridgecenter-10G
Double Column Machining Center
Specifications
| Table Size | 1,370 x 3,000 mm (53.9” x 118.1”) |
|---|---|
| Travel (X, Y, Z) | 2,540 x 1,615 x 800 mm (100.0” x 63.6” x 31.5”) |
| Spindle Taper | NST No. 50 |
| Spindle Speed | 35 – 12,000 rpm (Gear Drive, 4-Step) |
| Tool Storage Capacity | 40 tools (Optional: 60 / 80 tools) |
| Tool Change Time (T-T / C-C) | 6.6 sec / 14 sec |
| Rapid Feed Rate (X, Y, Z) | 24 m/min (945 ipm) |
| Power Requirement | 50 KVA |
Key Features & Advantages
- Designed for machining large components with high rigidity and precision
- Ideal for roughing and finishing large cavities and cores in die and mold applications
- High accuracy with positioning of ±0.000078” and repeatability of ±0.000039”
- Strong Meehanite cast iron construction with induction-hardened solid box ways for durability
- High-speed, high-torque 12,000 rpm gear-driven dual-contact spindle (#50 taper)
- Double column bridge-type design for a large work area and superior structural stability
- Linear scale feedback on X, Y, and Z axes for improved accuracy
- High-speed contour control with processing speeds up to 2,800 blocks/sec for smoother machining
- Heavy-duty table capacity of up to 13,300 lbs for handling large and heavy workpieces
